DQ510
1 SUMMARY
DQ510, an IC card reader and writer , designed by small size, low power check card (LPCD) and easy operation. This RFID module can read the main part of smart cards,suchi as ISO14443typeA and ISO14443typeB,ISO15693.
It has various functions and terms multi ISO/IEC standard of contactless card.Widely used in office/home security, personal identity, entrance guard system, security systems, intelligent instruments and meters, interactive toys and production process control ,which a variety of wireless radio frequency identification (RFID) system.
2 FEATURES
|
Computer interface |
|
|
Interface |
RS232；PC/SC；HID |
|
Power supply |
5V（±3%）,the lowest of power is 4.85V |
|
Power consumption |
Max 200mA |
|
Contactless smart card interface. |
|
|
Termsed standard |
ISO14443 TYPE- A,ISO14443 TYPE-B,ISO15693 |
|
Standardof contactless card |
ISO14443A,which is MIFARE Classic 1K/4K, FM11RF08, MIFARE Ultralight ISO14443A CPU, ISO14443 TYPE-B ISO15693 |
|
Working frequency |
13.56MHz |
|
Operating distance |
0-90mm（depending on card quality） |
|
Human-Computer Interface |
|
|
Status indication |
One tone, one red LED,one green LED,one buzzer |
|
Dimension |
118mm*76mm*17mm |
|
Environmental requirements |
|
|
Operating temperature |
-25~+85℃ |
|
Storagetemperature |
-40~+125℃ |
3 PICTURES
